  1. IBOX 1185G7E PC
  2. IBOX 1185G7E PLUS

IMB-1224E: Celeron 6305E, DC clocked up to 1.8GHz.SoC: Intel 11th Gen (Tiger Lake-UP3) Core Processors, up to 28W.This board also comes with the same graphics card support as the mini-STX motherboard with the addition of Intel UHD Graphics for Celeron processor. Similar to the STX-1500, this mini-ITX form factor motherboard supports all the Intel CPU variants including Celeron with 64GB DDR4 memory.

IBOX 1185G7E PLUS

“STX-1500 dual storage support with one M.2 Key M 2242/2260/2280 and two SATA 3 ports for connecting your storage devices plus RAID 0/1, and 12~28V DC-in to deliver increased computing efficiency for high-performance industrial applications.” IMB-1224 (Mini-ITX) Power Supply: 12~28V DC-In with 4-pin wafer PWR cable or DC Jack.Expansion: 1x M.2 with PCIe x1, USB 2.0 and CNVi for Wireless or 1x M.2 with PCIe x1 / USB 3.2 / USB2.0 and SIM for 4G/5G.eDP 1.4 with max resolution up to 4096×2304 at 60Hz refresh rate.LVDS dual-channel 24-bit up to 1920 x 1200 at 60Hz refresh rate.

ibox 1185g7e

  • HDMI 2.0a with maximum resolution up to 4096×2160 at 60Hz refresh rate.
  • Graphics: Intel Iris Xe Graphics for i7/i5 CPU / Intel UHD Graphics for i3 Processor.
  • Memory: Support dual channel DDR4 3200 MHz with 64GB (32GB per DIMM).
  • SoC: Intel 11th Gen (Tiger Lake-UP3) Core Processors, up to 28W TDP.
  • One of the important features in video output is the support for Quadruple display is provided via HDMI, eDP, and LVDS interfaces. The graphics are also Intel Iris Xe for the i7 and i5 CPUs while Intel UHD graphics for i3 CPU. This is a mini-STX form factor motherboard based on an Intel Tiger Lake-UP3 MCP processor that comes in three CPU variants clocked at different frequencies supporting dual-channel DDR4 64GB memory.

    ibox 1185g7e ibox 1185g7e

    ASRock has now announced Tiger Lake-based STX-1500 (Mini-STX), and IMB-1224 (Mini-ITX). The NUC 1100 Box Series came in three models – NUC BOX-1165G7, NUC BOX-1135G7, and NUC BOX-1115G4. After the release of the ASRock iBOX 1100 rugged mini-PC, several months in, we saw the NUC 1100 Box Series mini-PCs powered by the 11th Generation Intel Core i7/i5/i3 processors and Iris® Xe graphics a couple of months back.

    IBOX 1185G7E PC

    When it comes to industrial PC motherboards, we all know ASRock has successfully launched some of the popular products.
